Highlights
- Speed: 127 mm/sec.
- Connectivity: USB, Ethernet.
- Capacity: 11.2 cm.
Specifications
| Manufacturer reference | TD-4520TN |
|---|---|
| EAN code | 4977766798563 |
| Type | Label printer |
| Technology | Direct thermal / Thermal transfer |
| Maximum label width | 11.2 cm |
| Maximum print height | 10.5 cm |
| Print speed | 127 mm/sec |
| Resolution | 300 x 300 DPI |
| USB | Yes |
| Bluetooth | No |
| Wi-Fi | No |
| Ethernet | Yes |
| Serial port | 1 |
| Windows | Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Mac | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra... |
| AC adapter included | Yes |
| Display | No |
| Fonts | 8 |
| Built-in barcodes | AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 49, Code 93, EAN128, EAN13... |
| Languages | DPL, EPL, ZPL, ZPL II |
| Memory | 64 MB |
| Maximum roll diameter | 12.7 cm |
| Operating temperature | 10 - 90 °C |
| Dimensions (W x D x H) | 275 x 405 x 245 mm |
| Weight | 3.15 k g |
| Origin | China |
Consumables, maintenance parts and accessories
Use
Brother TD-4520TN label printer for retail, logistics and light industry: rolls up to 112 mm, direct thermal, sustained throughput.
Use cases: parcel and pallet labels, price and shelf labels, traceability, tickets, wristbands and laboratory labels. Driven from business software, an ERP or a terminal (ZPL, ESC/P, P-touch Template languages). Connectivity: USB, Ethernet. Software: P-touch Editor (PC and Mac) for layout, Excel list import and barcodes; Brother mobile app for printing from a smartphone. Consumables (tapes, rolls) are listed above; the price per label depends mostly on the media chosen.
The TD-4520TN is self-contained and complete for its category. For higher volumes or other options, see the TD-4650TNWB in the same series or Brother label printers.
Frequently asked questions
Which consumables does the TD-4520TN use?
See the list of compatible products above or the Brother manufacturer sheet.
Can the TD-4520TN be connected to a network?
Yes: USB, Ethernet.
Where can I find drivers and the manual?
On our Brother support page: drivers, user guide, software and FAQ for the TD-4520TN, by country.
